Overview - Impact Absorber And Glove Compartment Bracket

WARNING: This page is about a different variant/trim than selected.

Fig 1: Identifying Bumper And Glove Compartment Mount Components Overview

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Bolt
- 1.5 Nm
Front Passenger Side Deformation Element
- Removing and Installing. Refer to FRONT PASSENGER SIDE IMPACT ABSORBER, REMOVING AND INSTALLING .
Center Deformation Element
- Removing and Installing. Refer to CENTER IMPACT ABSORBER, REMOVING AND INSTALLING .
Driver Side Deformation Element
- Removing and Installing. Refer to IMPACT ABSORBER, REMOVING AND INSTALLING .
