Component Location Overview - Antenna System, Cabriolet
WARNING: This page is about a different variant/trim than selected.
- Screw
- 2 Nm
- Quantity: 3
- Satellite Antenna -R170-
- USA only
- Removing and installing, instrument panel. Refer to Satellite Antenna -R170- IN INSTRUMENT PANEL, REMOVING AND INSTALLING, CABRIOLET .
- Removing and installing, in the spoiler. Refer to Satellite Antenna -R170- IN SPOILER, REMOVING AND INSTALLING, CABRIOLET .
- Telephone Antenna -R65-
- Removing and Installing. Refer to TELEPHONE ANTENNA, REMOVING AND INSTALLING, CONVERTIBLE .
- GPS Antenna -R50-
- Removing and Installing. Refer to GPS ANTENNA, REMOVING AND INSTALLING, CONVERTIBLE .
- Screw
- 2 Nm
- Left Antenna Module -R108-
- FM2/DAB
- FM2/TV, Japan only
- FM2, USA only
- Removing and Installing. Refer to Left Antenna Module -R108-, REMOVING AND INSTALLING, CABRIOLET .
- Right Antenna Module -R109-
- AM (optional)/FM
- AM (optional)/FM/TV, Japan only
- Removing and Installing. Refer to Right Antenna Module -R109-, REMOVING AND INSTALLING, CABRIOLET .
- Screw
- 2 Nm
- Quantity: 2
- Satellite Antenna -R170- Mounting Plate
- USA only
- Only for auxiliary instruments
