Cylinder Numbering

WARNING: This page is about a different car, the 2014 Volkswagen Beetle and 2013 Volkswagen Beetle. However, it is still accessible from the selected car via links, so may be relevant.

-- Remove the air filter (engine cover). Refer to AIR FILTER HOUSING .

NOTE: Ignore -arrow-.

Fig 1: Disconnecting Harness Connector From Secondary Air Injection (AIR) Solenoid Valve N112

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

NOTE: Cylinder 1 is located opposite the fuel supply side.

Ignition sequence

1 - 2 - 4 - 5 - 3
