Overview - Emissions Control

WARNING: This page is about a different car, the 2015 Volkswagen Beetle. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Emissions Control Components

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Front Exhaust Pipe
- Removing and installing, refer to FRONT EXHAUST PIPE .
- Align the exhaust system free of tension, refer to EXHAUST SYSTEM, INSTALLING WITHOUT TENSION .
Screw-Type Clamp
- 7 Nm
- Replace after removing
Seal
- Note the installed position, refer to Figure.
Bolt
- Tightening specification and sequence, refer to Figure.
Seal
Screw-Type Clamp
- Installed position, refer to Figure
- Tightening specification and sequence, refer to Figure.
Exhaust Gas Recirculation (EGR) Cooler
- Removing and installing, refer to EXHAUST GAS RECIRCULATION (EGR) COOLER .
Bolt
- Tightening specification and sequence, refer to Figure.
Bolt
- Tightening specification and sequence, refer to Figure.
Bracket
- For cooler for Exhaust Gas Recirculation (EGR)
Screw-Type Clamp
- Tightening specification and sequence, refer to Figure.
Bolt
- Tightening specification and sequence, refer to Fig 2.
Turbocharger
- Removing and installing, refer to TURBOCHARGER .
Seal
- Place on the catalytic converter.
Bracket
- for emissions control module
- with adjusting element
- Prepare the adjusting element for installation, refer to INSTALLING
Bolt
Tightening specification and sequence, refer to Fig 2.

Fig 2: Emissions Control Module Bracket - Tightening Specifications And Tightening Sequence
Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Bolt
- Tightening specification and sequence, refer to Figure.
Bolt
- 9 Nm
Dial Gauge
- to the Differential Pressure Sensor -G505-
- Union nut tightening specification 45 Nm
Bolt
- Tightening specification and sequence, refer to Figure.
Bolt
- Tightening specification and sequence, refer to Fig 3.
Bracket
- for emissions control module
- with adjusting elements
- Prepare the adjusting elements for installation, refer to INSTALLING
Bolt
- Tightening specification and sequence, refer to Fig 3.
Emissions Control Module
- Particulate filter with catalytic converter
- Removing and installing, refer to EMISSIONS CONTROL MODULE .
Bolt
- Tightening specification and sequence, refer to Figure.

Fig 3: Emissions Control Module Bracket - Tightening Specifications And Tightening Sequence

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Tighten the bolts in steps according to the sequence:

Step	Bolts	Tightening Specification
1.	-3-	Install all the way in by hand.
2.	-1-	20 Nm
3.	-3-	20 Nm

Fig 4: Emissions Control Module Bracket - Tightening Specifications And Tightening Sequence

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
