Overview - Radio, Premium 8, 8AX: Notes

WARNING: This page is about a different car, the 2016 Volkswagen Beetle, 2015 Volkswagen Beetle, 2014 Volkswagen Beetle, and 2013 Volkswagen Beetle. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying RCD 510 Radio System

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Familiarity with the function and operation is needed if there are customer concerns. Refer to the Owner's Manual.

The Premium 8 radio has the following features:

Display: TFT (thin film transistor), touch screen
Integrated 6-disc CD changer
SD Memory Card Reader
UHV Low/Premium (stereo input)
4 speaker channels, each with 20 W
Connection for Multimedia System Control Module -J650-
External Audio Source Connection -R199-
Connection for the external CD Changer -R41- (not installed in the Beetle)
Connection for external sound amplifier (Amplifier -R12-)
OPS (optical parking system) on the radio display
A/C information shown in the radio display
Optional support for the multifunction steering wheel
Convenience coding
TIM (traffic information memory)
Optional integrated Satellite Radio -R146-

The integrated CD changer can play the following formats:

Audio CD
CD-R
CD-RW
MP3

It is not possible to play the following formats:

CD with 8 cm diameter
"Mix CDs" (CDs containing files and audio files)

The internal CD changer has a transportation safeguard, which must be deactivated when a new Radio -R- is installed, refer to Transportation Safeguard, Activating and Deactivating . Likewise, the transportation safeguard must be switched on, before a removed Radio -R- can be shipped. The Radio -R- must be connected to a power supply when doing this.

The Premium 8 is equipped with OBD.

For troubleshooting, use the Vehicle Diagnostic Tester in the "Guided Fault Finding" function.

Repairing Antenna Wires

Repairing antenna wires: Refer to GENERAL REPAIR INFORMATION .
