Component Location Overview - Antenna System, Convertible
WARNING: This page is about a different car, the 2016 Volkswagen Beetle, 2015 Volkswagen Beetle, 2014 Volkswagen Beetle, and 2013 Volkswagen Beetle. However, it is still accessible from the selected car via links, so may be relevant.
- Bolt
- 2 Nm
- Quantity: 3
- Satellite Antenna -R170-
- USA only
- (Without iPod® Docking) Instrument panel, removing and installing. Refer to Satellite Antenna -R170-, CONVERTIBLE, IN INSTRUMENT PANEL
- (With iPod® Docking) In the spoiler, removing and installing. Refer to Satellite Antenna -R170-, CONVERTIBLE, IN SPOILER
- Retainers
- GPS Antenna -R50-
- Removing and installing. Refer to GPS-Antenna -R50-, CONVERTIBLE .
- GPS Antenna -R50- Connector
- Screw
- 2 Nm
- Left Antenna Module -R108-
- FM2/DAB
- FM2/TV, Japan only
- FM2, USA only
- Removing and installing. Refer to Left Antenna Module -R108-, CONVERTIBLE .
Right Antenna Module -R109-
- AM/FM
- AM/FM/TV, Japan only
- Removing and installing. Refer to Right Antenna Module -R109-, CONVERTIBLE .
- Screw
- 2 Nm
- Quantity: 2
- Satellite Antenna -R170- Mounting Plate
- Only for auxiliary instruments
