Oil Pump: Removing
WARNING: This page is about a different car, the 2015 Volkswagen Beetle, 2014 Volkswagen Beetle, and 2013 Volkswagen Beetle. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the oil pan. Refer to OIL PAN .
-- If replacing the oil pump, remove the bolts -4- and the oil intake pipe -3-.
-- Remove the bolts -arrows- and the oil baffle -2-.
-- Disengage the oil pump -1- from the toothed belt and then remove it.
