Oil Pressure Switch -F1-: Removing

WARNING: This page is about a different car, the 2015 Volkswagen Beetle, 2014 Volkswagen Beetle, and 2013 Volkswagen Beetle. However, it is still accessible from the selected car via links, so may be relevant.

-- Remove the engine cover. Refer to ENGINE COVER .

-- Press the release buttons and remove the crankcase ventilation hose -1-.

Fig 1: Identifying Crankcase Ventilation Hose And Bolt

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Disconnect the connector and remove it from the crankcase ventilation hose -1-.

-- Expose the vacuum hoses -arrows-.

-- Remove air guide pipe from air filter housing by loosening hose clamps -3-.

-- Remove bolt -2- and tilt the air guide pipe with the intake hose backward and remove from the turbocharger.

-- Remove the bolts -2-, and remove the engine lifting eye -1-.

Fig 2: Identifying Electrical Connector

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Disconnect the connector -arrow-.

-- Remove the Oil Pressure Switch -F1-.
