Side Window Vents: Removing

WARNING: This page is about a different car, the 2016 Volkswagen Beetle, 2015 Volkswagen Beetle, 2014 Volkswagen Beetle, and 2013 Volkswagen Beetle. However, it is still accessible from the selected car via links, so may be relevant.

-- Release the side window vent locking mechanisms -1- and -4- using the Trim Removal Wedge 3409 and remove them from the instrument panel -3-.

Fig 1: Identifying Side Window Vent Locking Mechanisms
GWWM80-10009Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
