Overview - Front Passenger Airbag

Fig 1: Exploded View Of Front Passenger Airbag Components

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Connector
- For Front Passenger Airbag Igniter 1 -N131-
Bolts
- 8 Nm
- Replace or before installing clean with Locking Fluid. Refer to the appropriate service information for the allocation.
- Quantity: 2
Instrument Panel
- Replace the instrument panel after an airbag has deployed. Refer to INSTRUMENT PANEL, REMOVING AND INSTALLING .
Bolts
- 8 Nm
- Replace or before installing clean with Locking Fluid. Refer to the appropriate service information for the allocation.
- Quantity: 2
Front Passenger Airbag
- With Front Passenger Airbag Igniter 1 -N131-
  WARNING:
  - Observe the safety precautions for pyrotechnical components. Refer to SAFETY PRECAUTIONS .
  - Observe the allocation of the airbag unit for the instrument panel. Refer to the appropriate service information.
- Removing and Installing. Refer to FRONT PASSENGER AIRBAG UNIT WITH IGNITER, REMOVING AND INSTALLING .
