Overview - Hood Operating Lever

Fig 1: Identifying Hood Release Assembly
GWWN55-10303
  1. Bracket
  2. Release Lever
  3. Clip
  4. Bolt
    • Tightening specification 1.5 Nm.
    • Quantity: 2
  5. Release Cable
    • Clipped into mounting bracket
  6. Bracket
  7. Insert Nut
    • Quantity: 2
