Overview - Coolant Pump/Coolant Thermostat
WARNING: This page is about a different variant/trim than selected.
- O-rings
- Replace after removing.
- Coat with coolant
- Connection
- O-ring
- Replace after removing.
- Coat with coolant
- Lower Front Coolant Pipe
- Removing and installing. Refer to LOWER FRONT COOLANT PIPE, REMOVING AND INSTALLING .
- Seal
- Replace after removing.
- O-ring
- Replace after removing.
- Coat with coolant
- Coolant Pump
- Removing and installing. Refer to COOLANT PUMP, REMOVING AND INSTALLING .
- O-rings
- Replace after removing.
- Coat with coolant
- Bolt
- 8 Nm
- Cylinder Head Coolant Valve -N489-
- Removing and installing. Refer to Cylinder Head Coolant Valve -N489-, REMOVING AND INSTALLING .
- Bolt
- 20 Nm +45°
- Replace after removing.
- Clip
- Check for secure fit
- Clip
- Check for secure fit
- O-ring
- Replace after removing.
- Coat with coolant
- Seal
- Replace after removing.
- Bolt
- 20 Nm
- Coolant Thermostat Housing
- O-ring
- Replace after removing.
- Coat with coolant
- Coolant Thermostat
- Removing and installing. Refer to COOLANT THERMOSTAT, REMOVING AND INSTALLING .
- Bolt
- 20 Nm
- Connection
