Overview - Turbocharger: Notes
WARNING: This page is about a different variant/trim than selected.
- Banjo Bolt
- 30 Nm
- Oil Supply Line
- Check for flow
- Before installing, fill the turbocharger with engine oil at the oil supply line connection
- Bolt
- 12 Nm
- Union Nut
- 22 Nm
- Exhaust Gas Temperature Sensor 1 -G235-
- Overview. Refer to OVERVIEW - EXHAUST TEMPERATURE REGULATION .
- Bolt
- Tightening specification and sequence. Refer to Emissions Control Module Bracket - Tightening Sequence .
- Bolt
- 15 Nm
- Heat Shield
- O-ring
- Replace after removing.
- Pulsation Damper
- Bolt
- 8 Nm
- Turbocharger Connection
- Removing and installing. Refer to TURBOCHARGER CONNECTIONS, REMOVING AND INSTALLING .
- Bolt
- 8 Nm
- O-ring
- Replace after removing.
- Bracket
- For wires
- Bolt
- 15 Nm
- Heat Shield
- Turbocharger
- Removing and installing. Refer to TURBOCHARGER, REMOVING AND INSTALLING .
- Seal
- Replace after removing.
- Nut
- Tightening specification and sequence. Refer to Locating Nuts .
- Replace after removing.
- Bracket
- For the emissions control module
- Bolt
Tightening specification and sequence. Refer to Emissions Control Module Bracket - Tightening Sequence .
- Seal
- Replace after removing.
- O-ring
- Replace after removing.
- Coat with engine oil
- Oil Return Line
- Bolt
- 10 Nm
- Ribbed Bolt
- 14 Nm
- Seals
- Replace after removing.
