Special Tools

WARNING: This page is about a different variant/trim than selected.

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Special tools and workshop equipment required

Engine Support Bridge :10-222A
Engine Support Bridge - Spindle :10-222A/11 quantity: 2
Engine Support Bridge - Engine Support 28 :10-222A/28 quantity 2
Engine Support Bridge - Engine Support 28-2 :10-222A/28-2 quantity: 2
Engine Support Bridge - Engine Support 31 :10-222A/31
Engine Support - Basic Set - Rail with Holes :T40091/2 from the Engine Support - Basic Set :T40091
Engine Support - Supplement Kit Mount 5 :T40093/5 from the Engine Support - Supplement Kit :T40093A
Square Pipe :T40091/1 (quantity 2) from the Engine Support - Basic Set :T40091
Movable Joint :T40091/3 (quantity 2) from the Engine Support - Basic Set :T40091
Movable Joint :T40093/4 (quantity 2) from the Engine Support - Supplement Kit :T40091

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Special tools and workshop equipment required

Special tools and workshop equipment required

Used Oil Collection and Extraction Unit :SMN372500

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Socket - Xzn 14 :T10061

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Bits for VAG1331/13 :T10099

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Guide Bolt - Mechatronic :T10406

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Assembly Lever - Mechatronic :T10407

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Suction Pump :VAS5226

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Oil Filler :VAS6262A with Adapter For Oil Filling :VAS6262/4

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Adapter VAS6262/7 :VAS6262/7

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Engine Support Bridge - Additional Hooks (2 pc.) :10-222A/2

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Pry Lever :80-200

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Trim Removal Wedge :3409

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Vehicle Diagnostic Tester
