Overview - Camshaft Housing: Notes
WARNING: This page is about a different variant/trim than selected.
- Cylinder Head
- Ball Pin
- 9 Nm
- For engine cover
- O-ring
- Replace after removing
- Coat with engine oil
- Plugs
- Oil Separator
- Removing and installing. Refer to OIL SEPARATOR, REMOVING AND INSTALLING .
- Bolt
- Tightening specification and sequence. Refer to Figure.
- Seal
- Replace after removing
- Vacuum Pump
- Removing and installing. Refer to VACUUM PUMP, REMOVING AND INSTALLING .
- Bolt
- Tightening specification. Refer to Figure.
- Gasket
- Replace if damaged
- O-ring
- Replace after removing
- Coat with engine oil
- Camshaft Position Sensor -G40-
- Overview. Refer to OVERVIEW - IGNITION SYSTEM .
- Bolt
- Tightening specification. Refer to OVERVIEW - IGNITION SYSTEM .
- Bolts
- 9 Nm
- Bracket
- For EVAP Canister Purge Regulator Valve 1 -N80-
