Overview - Toothed Belt Guard
WARNING: This page is about a different variant/trim than selected.
- Bolts
- 8 Nm
- Lower Toothed Belt Guard
- Engine Mount Bracket
- Tightening specification and sequence. Refer to ENGINE BRACKET, REMOVING AND INSTALLING .
- Upper Toothed Belt Guard
- Spring Clip
- Make sure both spring clips are secure.
- Bolt
- 8 Nm
