Tightening Specifications And Sequence For Engine Bracket

WARNING: This page is about a different variant/trim than selected.

-- Tighten the bolts in the steps shown in the sequence:

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Step	Component	Tightening Specification/Additional Turn
1	Bolts -1 through 3-	Install loosely
2	Bolts -1 through 3-	Push the engine mount bracket upward in direction of -arrow- and tighten it hand-tight so that it cannot move anymore.
3	Bolts -1 through 3-	Tighten to 40 Nm
4	Bolts -1 through 3-	90° additional turn

Fig 1: Pendulum Support / Subframe Tightening Sequence

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

NOTE:

Replace the bolts that were tightened with an additional turn.

-- Tighten the bolts in the steps shown in the sequence:

Step	Component	Tightening Specification/Additional Turn
1	Bolts -2 and 3-	50 Nm
2	Bolt -1-	130 Nm
3	Bolts -1 through 3-	90° additional turn
