Overview - Belt Pulley Side Sealing Flange: Notes
WARNING: This page is about a different variant/trim than selected.
- Bolt
- 150 Nm +180°
- Replace after removing.
- Vibration Damper
- Removing and installing. Refer to VIBRATION DAMPER, REMOVING AND INSTALLING .
- Seal
- Replace after removing. Refer to CRANKSHAFT SEAL, REPLACING, BELT PULLEY SIDE .
- For the vibration damper crankshaft
- Do not oil
- Sealing Flange, Belt Pulley Side
- Must be seated on the alignment pins
- Removing and installing. Refer to SEALING FLANGE, REMOVING AND INSTALLING, BELT PULLEY SIDE .
- Bolt
- Tightening specification and sequence. Refer to Tightening Specifications With Sequence .
- Replace after removing.
- There are different thread diameters.
- Seal
- Replace after removing.
- Cylinder Block
- Alignment Pin
- Quantity: 2
- Bolt
- Replace after removing.
- Tightening specification and sequence. Refer to Tightening Specifications With Sequence .
