Engine Bracket, Removing And Installing: Removing

WARNING: This page is about a different variant/trim than selected.

-- Remove the engine mount. Refer to ENGINE MOUNT, REMOVING AND INSTALLING .

-- Remove the toothed belt. Refer to TOOTHED BELT, REMOVING AND INSTALLING .

-- Remove the bolt -6- from the coolant pump bracket.

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Remove the bolts -1 through 3- and the engine mount bracket.

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
