Rear Side Airbag: Installing

-- Install in reverse order of removal.

-- When installing, replace all 11 clamping washers -1-.

Fig 1: Identifying 11 Clamping Washers -1-
GWWN69-10349Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Switch on ignition.

WARNING:

Make sure no one is in the vehicle.

-- Connect the battery. Refer to [For transmission(s) 0A6, 09M] Removal and Installation
