Engine, disassembling and assembling

WARNING: This page is about a different variant/trim than selected.
NOTE:
  • If large quantities of metal particles or other deposits (caused, for example, by partial seizure of the crankshaft or connecting rod damage) are found in the engine oil, the oil passages must be cleaned thoroughly and the oil cooler replaced in order to prevent further damage from re-occurring.
  • Faulty injectors can cause violent knocking noises in the engine which sound like faulty bearings. When this occurs, run the engine at idle and loosen injector line unions one after the other. If the knocking stops when a specific union is loosened, it is an indication that the respective injector is faulty.

Fuel injectors, servicing. Refer to 23 DIESEL FUEL INJECTION for M.Y. 99-01, or 23 DIESEL FUEL INJECTION from M.Y. 2002 and on

I - Part I

II - Part II

Fig 1: Exploded View Of Crankshaft - Parts I & II
GW00000713Courtesy of VOLKSWAGEN UNITED STATES, INC.
