Pressure line on 5-speed manual transmission 02J and 5-speed manual transmission 02T, securing
WARNING: This page is about a different variant/trim than selected.
Courtesy of VOLKSWAGEN UNITED STATES, INC.
1 - Pressure line
2 - Speed nut
3 - Clamp
4 - Hex head bolt, 22 Nm
5 - Hex nut, 22 Nm
6 - Bracket
7 - Pressure hose
8 - Hex head bolt, 22 Nm
