Noise Generator Overview
WARNING: This page is about a different car, the 2010 Volkswagen Jetta, 2009 Volkswagen Jetta, 2009 Volkswagen GLI, 2008 Volkswagen Jetta, and 2008 Volkswagen GLI. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Charge Air Pipe from the noise generator removing and installing. Refer to CHARGE AIR PIPE FROM NOISE GENERATOR .
The noise generator is not installed on all vehicles. As of 04.09, the noise generator is replaced by the structure-borne sound actuator -R214-. Refer to Structure-Borne Sound Actuator -R214- AND Structure-Borne Sound Control Module -J869- OVERVIEW .
- Cover
- Bolt
- 8 Nm
- Plenum Chamber Bulkhead
- Hood
- For the duct to the plenum chamber bulkhead.
- Charge Air Pipe
- Connecting and disconnecting, refer to CHARGE AIR HOSE AND PIPE, DISCONNECTING AND CONNECTING .
- Hose Clamp
- Charge Air Hose
- Bolt
- 8 Nm
- Spacer Sleeve
- Rubber Bushing
- Noise Generator
- Before removal, remove the cover, refer to "Cover" in item: 1.
- Bracket
- For the noise generator.
- Nut
- 8 Nm
