Fuel Injectors, removing and installing: Installing
WARNING: This page is about a different car, the 1996 Volkswagen Jetta. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION:
Always install a new heat shield between cylinder head and injectors.
Installing heat shield:
- Arrow points toward cylinder head.
Tightening torques:
- Injection lines: 25 Nm (18 ft lb)
- Injectors: 70 Nm (52 ft lb)
