Rear tweeter (4-door, except Jetta from 1996 m.y.), removing and installing

WARNING: This page does not describe the selected car, but rather 27 other vehicles, including the 2002 Volkswagen Cabrio, 2001 Volkswagen Cabrio, 2000 Volkswagen Cabrio, 1999 Volkswagen Jetta, and 1999 Volkswagen Golf. However, it is still accessible from the selected car via links, so may be relevant.
  1. Door release lever trim
  2. Tweeter
    • Carefully remove door release lever trim -1- (with tweeter -2-).
      • Fig 1: Removing Rear Tweeter (4-Door, Except Jetta From 1996 M.Y.)
      G03364240Courtesy of VOLKSWAGEN OF AMERICA, INC.
    • Remove connector.
    • Install in reverse order of removal.
