Jetta, installed position

WARNING: This page does not describe the selected car, but rather 27 other vehicles, including the 2002 Volkswagen Cabrio, 2001 Volkswagen Cabrio, 2000 Volkswagen Cabrio, 1999 Volkswagen Jetta, and 1999 Volkswagen Golf. However, it is still accessible from the selected car via links, so may be relevant.

Rear side rail of luggage compartment floor, ahead of left tail light assembly.

NOTE: The following list refers to items in Fig 1 .
  1. CD changer
  2. CD changer bracket
  3. Self tapping screw (4.8x19)
  4. Self tapping screw (5x8)
  5. Support
  6. Self tapping screw (4.8x19) and washer (5.3x10x1)
Fig 1: Installing Rear Side Rail Of Luggage Compartment Floor (Jetta)
G03364273Courtesy of VOLKSWAGEN OF AMERICA, INC.
