Installing vacuum hose adaptor

WARNING: This page does not describe the selected car, but rather 27 other vehicles, including the 2002 Volkswagen Cabrio, 2001 Volkswagen Cabrio, 2000 Volkswagen Cabrio, 1999 Volkswagen Jetta, and 1999 Volkswagen Golf. However, it is still accessible from the selected car via links, so may be relevant.

When replacing the heater core -1- on vehicles with A/C, or with fresh/recirculating air flap:

Install vacuum hose adaptor -2- on new heater core.
Replace gasket -3-.

Fig 1: Installing Vacuum Hose Adaptor

Courtesy of VOLKSWAGEN OF AMERICA, INC.
