Upper D-pillar trim, removing and installing (Golf wagon/Jetta wagon): Installing

CAUTION: Before installing trim - 2  - , check clips - 3  - and mounting sleeves - 4  - for damage, replace if necessary.

NOTE:

• Steel clips and D-pillar trim parts can no longer be ordered separately for vehicles with side curtain protection → parts catalog.

• Insert clips - 3  - into mounts for trim - 2  - and press mounting sleeves - 4  - into C-pillar holes.
• Insert lower edge of D-pillar trim panel - 2  - behind luggage compartment side trim and clip into D-pillar.
• Secure trim - 2  - in roof area with bolt - 1  -.

• Install roof end strip → Roof end trim, removing and installing (Golf wagon/Jetta wagon)  .

Fig 1: Upper D-Pillar Trim Assembly Overview (Golf Wagon/Jetta Wagon)

Courtesy of VOLKSWAGEN UNITED STATES, INC.
