Instrument panel, removing and installing: Installing
WARNING: This page is about a different variant/trim than selected.
Installation is performed in the reverse order of removal.
NOTE:
- If Airbag Malfunction Indicator Lamp (MIL) -K75- signals a DTC after assembling n DTC memory must be erased and checked again using VAG 1551 tester (or VAS 5051) → 01 ON BOARD DIAGNOSTIC (OBD)
- If engine Electronic Control Module (ECM) is subject to low voltage with ignition on, DTC memory and Readiness code must be checked → 01 ON BOARD DIAGNOSTIC (OBD) for 1.8 LITER 4-CYL. 5V TURBO FUEL INJECTION & IGNITION, ENGINE CODE(S): AWD (A4 PLATFORM), 01 ON BOARD DIAGNOSTIC (OBD) for 1.8 LITER 4-CYL. 5V TURBO FUEL INJECTION IGNITION, ENGINE CODE(S): AWW, AWP (A4 PLATFORM), 01 ON BOARD DIAGNOSTIC (OBD) for 1.9 LITER 4-CYL. 2V TDI FUEL INJECTION GLOW PLUG, ENGINE CODE ALH, FROM MY 2002 (A4 PLATFORM), 01 ON BOARD DIAGNOSTIC (OBD) for 1.9 LITER 4-CYL. 2V TDI FUEL INJECTION GLOW PLUG, ENGINE CODE: ALH, MY 1999-2001 (A4 PLATFORM), 01 ON BOARD DIAGNOSTIC (OBD) for 2.8 LITER VR6 2V FUEL INJECTION IGNITION, ENGINE CODE(S): AFP (A4 PLATFORM) or 01 ON BOARD DIAGNOSTIC (OBD) for 2.8 LITER VR6 4V FUEL INJECTION IGNITION. ENGINE CODE(S): BDF (A4 PLATFORM) .
