Backrest upper part, removing

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2002 Volkswagen Cabrio, 2001 Volkswagen Cabrio, 2000 Volkswagen Cabrio, 1999 Volkswagen Cabrio, and 1998 Volkswagen Cabrio. However, it is still accessible from the selected car via links, so may be relevant.

Remove backrest lower part and fold seat up.
Remove left and right bolt -1- 40 N.m (30 ft lb) and take seat belt anchor off.

Fig 1: Removing Backrest Upper Part

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pry rear bulkhead trim -1- out of backrest upper part flange and pull off rearward.

NOTE: Upper area of rear bulkhead trim is bonded to backrest upper part. When installing use universal adhesive D 001 200.

Remove bolts -2- pull seat belt out of backrest upper part and take backrest upper part off.

Fig 2: Removing Rear Bulkhead Trim & Bolts

Courtesy of VOLKSWAGEN OF AMERICA, INC.
