Fuel Lid Opener Switch
>>
Components [06/2020 - ]
Components [06/2020 - ]
Fig 1: Fuel Lid Opener Switch Replacement Components
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1
COWL SIDE TRIM BOARD LH
*2
FRONT DOOR OPENING TRIM WEATHERSTRIP LH
*3
FRONT DOOR SCUFF PLATE LH
*4
FUEL LID OPENER SWITCH
*5
FUSE BOX OPENING COVER
*6
NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY
