Reassembly [06/2020 - ]: Procedure

  1. INSTALL SPOT LIGHT ASSEMBLY

    Refer to PROCEDURE - Step 1

  2. INSTALL PUSH START SWITCH BRACKET
    1. Attach the claw and install the push start switch bracket.
      GTY1008260Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
