Components [06/2020 - ]

Fig 1: Combination Switch Replacement Components
GTY983136Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 INTEGRATION CONTROL AND PANEL ASSEMBLY *2 SHIFT POSITION INDICATOR
*3 UPPER CONSOLE PANEL SUB-ASSEMBLY - -
