Caution / Notice / Hint

COMPONENTS (REMOVAL)

Fig 1: Reserve Lock Switch Removal Components
GTY1142501Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout - Procedure Part Name Code
1 GLIDE DOOR INSIDE HANDLE BASE ASSEMBLY 69290G See step  1 - -
2 BACK DOOR CONTROL SWITCH 84931C - - -
