Caution / Notice / Hint
The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed, installed or replaced during the rear roof rack bracket removal/installation are shown below.
HINT:
- When the cable is disconnected/reconnected to the auxiliary battery terminal, systems temporarily stop operating. However, each system has a function that completes learning the first time the system is used.
- Learning completes when vehicle is driven
| Effect/Inoperative Function When Necessary Procedures are not Performed |
Necessary Procedures |
Link |
| Front camera system |
Drive the vehicle straight ahead at 35 km/h (22 mph) or more for 5 seconds or more. |
Refer to INITIALIZATION [02/2024 - ] |
- Learning completes when vehicle is operated normally
| Effect/Inoperative Function When Necessary Procedures are not Performed |
Necessary Procedures |
Link |
| Air conditioning system |
After the ignition switch is turned to ON, the servo motor standard position is recognized. |
- |
| Power back door system |
Fully close the back door by hand.
HINT:
Initialization is not necessary if the above procedures are performed while the back door is closed. |
Refer to INITIALIZATION [02/2024 - ] |
- Use the same procedure for the RH and LH sides.
- The procedure described below is for the LH side.
