Removal [02/2024 - ]: Procedure

  1. REMOVE REAR QUARTER PANEL MUDGUARD LH
    1. for Type A:
      GTY1224987Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      Screw Clip
      1. Using a 4 mm hexagon socket wrench, remove the 3 screws.
      2. Remove the clip and rear quarter panel mudguard LH.
    2. for Type B:
      GTY1223983Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      Screw Clip
      1. Using a 4 mm hexagon socket wrench, remove the 4 screws.
      2. Remove the clip and rear quarter panel mudguard LH.
