Caution / Notice / Hint

COMPONENTS (REASSEMBLY)

Fig 1: Grille Shutter Reassembly Components
GTY1213142Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Procedure Part Name Code
1 NO. 1 RADIATOR GRILLE SEAL 53155C See step  1 - -
2 NO. 2 RADIATOR GRILLE SEAL 53156F See step  2 - -
• Non-reusable part - -
