Removal [02/2024 - ]: Procedure

  1. REMOVE RADIATOR SHUTTER ASSEMBLY

    Refer to REMOVAL [02/2024 - ]

  2. REMOVE MILLIMETER WAVE RADAR SENSOR ASSEMBLY
    1. GTY1223135Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      Connector Bolt
      Screw - -
