Removal [02/2024 - ]: Procedure

REMOVE FRONT PILLAR UPPER COVER SUB-ASSEMBLY LH

NOTE:

When removing the front pillar upper cover sub-assembly LH, if the double-sided tape is difficult to remove, heat the adhesive of the front pillar upper cover sub-assembly LH using a heat light.

Standard Value

Part	Temperature
Front Pillar Upper Cover Sub-assembly LH	20 to 30°C (68 to 86°F)

WARNING:

Do not touch the heat light and heated parts.
Touching the heat light may result in burns.
Touching heated parts for a long time may result in burns.

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*a	Heated Part
*b	Heat Light

NOTE:

Do not heat the front pillar upper cover sub-assembly LH excessively.

*a	Double-sided Tape	-	-
	Remove in this Direction	-	-

Put protective tape around the front pillar upper cover sub-assembly LH.
Heat the adhesive of the front pillar upper cover sub-assembly LH using a heat light.
Detach the clip and remove the front pillar upper cover sub-assembly LH as shown in the illustration.
