Components [09/2022 - ]

WARNING: This page is about a different variant/trim than selected.

Fig 1: Motor Cable Replacement Components With Torque Specifications (1 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Callout	Description	Callout	Description
*A	Type A	*B	Type B
*1	NO. 1 ENGINE UNDER COVER ASSEMBLY	-	-
	N.m (kgf/cm, ft.lbf): Specified torque	-	-

Fig 2: Motor Cable Replacement Components With Torque Specifications (2 Of 2)

Callout	Description	Callout	Description
*1	FILLER PLUG	*2	DRAIN PLUG
*3	GASKET	-	-
	N.m (kgf/cm, ft.lbf): Specified torque	•	Non-reusable part
