Parts Location [01/2019 - ]: Illustration
WARNING: This page is about a different variant/trim than selected.
 Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
|
| *1 |
IGNITION COIL ASSEMBLY |
*2 |
SPARK PLUG |
| *3 |
ECM |
*4 |
NO. 1 ENGINE ROOM RELAY BLOCK AND NO. 1 JUNCTION BLOCK ASSEMBLY
-INJ FUSE |
