DTC B15C5-11: Emergency Call Switch Circuit Short to Ground; DTC B15C5-13: Emergency Call Switch Circuit Open [10/2022 - ]: Wiring Diagram

for 9 Speakers:

GTY1110413Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

for 6 Speakers:

GTY1110414Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
