Removal [11/2021 - ]: Procedure

  1. REMOVE AIR CONDITIONING CONTROL ASSEMBLY

    Refer to REMOVAL [11/2021 - ]

  2. REMOVE FRONT NO. 4 SPEAKER ASSEMBLY
    1. GTY1051153Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
