Exterior Panels / Trim - Service Information (2 Of 2)
>>
Roof Drip Side Finish Moulding
>>
Components [07/2020 - ]
Components [07/2020 - ]
Fig 1: Roof Drip Side Finish Moulding Replacement Components
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout
Description
Callout
Description
*A
w/o Roof Rack
*B
w/ Roof Rack
*C
for Normal Roof
*D
for Glass Roof
*1
REAR ROOF DRIP SIDE FINISH MOULDING
*2
ROOF DRIP SIDE FINISH MOULDING
*3
ROOF DRIP SIDE FINISH MOULDING CLIP
-
-
•
Non-reusable part
-
-
