Removal [07/2020 - 10/2022]: Procedure

  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY

    Refer to REMOVAL [07/2020 - 10/2022]

  2. REMOVE METER MIRROR SUB-ASSEMBLY
    1. Disconnect the connector.
      GTY987511Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. Remove the 2 nuts and meter mirror sub-assembly.
