Caution / Notice / Hint

The necessary procedures (adjustment, calibration, initialization, or registration) that must be performed after parts are removed and installed, or replaced during brake pedal support assembly removal/installation are shown below.

*1: Even when not replacing the part, it is necessary to perform the specified necessary procedures after installation.

HINT:

• When the cable is disconnected / reconnected to the auxiliary battery terminal, systems temporarily stop operating. However, each system has a function that completes learning the first time the system is used.
  • Learning completes when vehicle is driven

    Effect/Inoperative Function When Necessary Procedures are not Performed	Necessary Procedures	Link
    Lane tracing assist system	Drive the vehicle straight ahead at 35 km/h (22 mph) or more for 5 seconds or more.	Refer to INITIALIZATION [06/2020 - ]
    Pre-collision system
    Lighting system (EXT) (w/ AFS)

  • Learning completes when vehicle is operated normally

    Effect/Inoperative Function When Necessary Procedures are not Performed	Necessary Procedures	Link
    Power back door function	Fully close the back door by hand. HINT:  Initialization is not necessary if the above procedures are performed while the back door is closed.	Refer to INITIALIZATION [06/2020 - 10/2023]
    Power door lock control system	If the back door is locked and therefore cannot be opened, it is necessary to unlock the back door using the door control switch, electrical key transmitter sub-assembly switch.	Refer to INITIALIZATION [06/2020 - ]
    Air conditioning system	After the ignition switch is turned to ON, the servo motor and expansion valve standard position is recognized.	-
