Components [10/2022 - ]

Fig 1: Trip Switch Replacement Components
GTY1122174Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*A for Gasoline Model - -
*1 COWL SIDE TRIM BOARD LH *2 FRONT DOOR SCUFF PLATE LH
*3 FUEL LID LOCK OPEN LEVER SUB-ASSEMBLY *4 FUSE BOX OPENING COVER
*5 HOOD LOCK CONTROL LEVER SUB-ASSEMBLY *6 NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY
*7 TRIP SWITCH - -
