Installation [11/2021 - 12/2022]: Procedure

HINT:

The illustrations are representative examples, and details may differ.

1. Fig 1: Meter Mirror Sub-Assembly Tightening Sequence

   Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
   1. Connect each connector.
   2. Temporarily install the meter mirror sub-assembly with the 3 bolts.
   3. Tighten the 3 bolts in the order shown in the illustration, install the meter mirror sub-assembly.

      Torque: 10 N.m (102 kgf/cm, 7 ft.lbf)

Refer to INSTALLATION [11/2020 - 12/2022]

Refer to WORK PROCEDURE [11/2020 - 12/2022]

HINT:

When disconnecting and reconnecting the auxiliary battery, there is an automatic learning function that completes learning when the respective system is used.

Refer to AUTOMATIC LEARNING CHART [11/2021 - 12/2023]
