Electric Parking Brake does not Operate [12/2023 - ]: Wiring Diagram

With Front LiDAR Sensor

Fig 1: With Front LiDAR Sensor [12/2023 - ]

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Without Front LiDAR Sensor

Fig 2: Without Front LiDAR Sensor [12/2023 - ]

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
