Reassembly [11/2022 - ]: Procedure

WARNING: This page is about a different car, the 2025 Toyota Corolla Cross, 2024 Toyota Corolla Cross, 2023 Toyota Corolla Cross, and 2022 Toyota Corolla Cross. However, it is still accessible from the selected car via links, so may be relevant.
  1. INSTALL NO. 3 ROOF DRIP SIDE FINISH MOULDING SEAL
    1. GTY1178506Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      1. Clean the surface of the roof rack.

        1. Using a heat light, heat the roof rack.

        Standard

        Item Temperature Item Temperature
        Roof Rack 20 to 30°C (68 to 86°F) - -
        WARNING:
        • Do not touch the heat light and heated parts.
        • Touching the heat light may result in burns.
        • Touching heated parts for a long time may result in burns.
        GTY583249Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
        *a Heated Part
        *b Heat Light
        NOTE:

        Do not heat the roof rack excessively.

        2. Remove any remaining double-sided tape from the roof rack.

        3. Wipe off any tape adhesive residue with cleaner.

        NOTE:
        • Installing the No. 3 roof drip side finish moulding seal with some double-sided tape remaining may cause poor adhesion. Perform this procedure until the tape is sufficiently removed.
        • Make sure to use a cloth when removing. Using a screwdriver, etc., may cause damage and poor adhesion.
      2. Apply primer to the roof rack.

        1. Apply primer to the roof rack on the installation area of the No. 3 roof drip side finish moulding seal using a brush or felt.

        NOTE:
        • Replace the brush or felt if it is dirty or has become hardened.
        • Do not touch surfaces to which primer has been applied until the roof rack has been attached.

        2. Let the primer dry sufficiently.

        Recommended drying time

        10 minutes or more (at 23°C (73°F))

        NOTE:

        Do not touch applied surfaces until the primer is dry.

      3. Install a new No. 3 roof drip side finish moulding seal.

        1. Using a heat light, heat the roof rack.

        Standard

        Item Temperature Item Temperature
        Roof Rack 20 to 30°C (68 to 86°F) - -
        WARNING:
        • Do not touch the heat light and heated parts.
        • Touching the heat light may result in burns.
        • Touching heated parts for a long time may result in burns.
        NOTE:

        Do not heat the roof rack excessively.

        2. Remove the release paper from the No. 3 roof drip side finish moulding seal.

        HINT:

        After removing the release paper, keep the exposed adhesive free from foreign matter.

        3. Install the No. 3 roof drip side finish moulding seal as shown in the illustration.

        HINT:

        • Install the No. 3 roof drip side finish moulding seal along the location line on the roof rack.
        • Press the No. 3 roof drip side finish moulding seal firmly to install it.
  2. INSTALL REAR ROOF DRIP SIDE FINISH MOULDING SEAL
    1. GTY1177992Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      1. Clean the surface of the roof rack.

        1. Using a heat light, heat the roof rack.

        Standard

        Item Temperature Item Temperature
        Roof Rack 20 to 30°C (68 to 86°F) - -
        WARNING:
        • Do not touch the heat light and heated parts.
        • Touching the heat light may result in burns.
        • Touching heated parts for a long time may result in burns.
        GTY583249Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
        *a Heated Part
        *b Heat Light
        NOTE:

        Do not heat the roof rack excessively.

        2. Remove any remaining double-sided tape from the roof rack.

        3. Wipe off any tape adhesive residue with cleaner.

        NOTE:
        • Installing the rear roof drip side finish moulding seal with some double-sided tape remaining may cause poor adhesion. Perform this procedure until the tape is sufficiently removed.
        • Make sure to use a cloth when removing. Using a screwdriver, etc., may cause damage and poor adhesion.
      2. Apply primer to the roof rack.

        1. Apply primer to the roof rack on the installation area of the rear roof drip side finish moulding seal using a brush or felt.

        NOTE:
        • Replace the brush or felt if it is dirty or has become hardened.
        • Do not touch surfaces to which primer has been applied until the roof rack has been attached.

        2. Let the primer dry sufficiently.

        Recommended drying time

        10 minutes or more (at 23°C (73°F))

        NOTE:

        Do not touch applied surfaces until the primer is dry.

      3. Install a new rear roof drip side finish moulding seal.

        1. Using a heat light, heat the roof rack.

        Standard

        Item Temperature Item Temperature
        Roof Rack 20 to 30°C (68 to 86°F) - -
        WARNING:
        • Do not touch the heat light and heated parts.
        • Touching the heat light may result in burns.
        • Touching heated parts for a long time may result in burns.
        NOTE:

        Do not heat the roof rack excessively.

        2. Remove the release paper from the rear roof drip side finish moulding seal.

        HINT:

        After removing the release paper, keep the exposed adhesive free from foreign matter.

        3. Install the rear roof drip side finish moulding seal as shown in the illustration.

        HINT:

        • Install the rear roof drip side finish moulding seal along the location line on the roof rack.
        • Press the rear roof drip side finish moulding seal firmly to install it.
  3. INSTALL FRONT ROOF DRIP SIDE FINISH MOULDING SEAL
    1. GTY1177716Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      1. Clean the surface of the roof rack.

        1. Using a heat light, heat the roof rack.

        Standard

        Item Temperature Item Temperature
        Roof Rack 20 to 30°C (68 to 86°F) - -
        WARNING:
        • Do not touch the heat light and heated parts.
        • Touching the heat light may result in burns.
        • Touching heated parts for a long time may result in burns.
        GTY583249Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
        *a Heated Part
        *b Heat Light
        NOTE:

        Do not heat the roof rack excessively.

        2. Remove any remaining double-sided tape from the roof rack.

        3. Wipe off any tape adhesive residue with cleaner.

        NOTE:
        • Installing the front roof drip side finish moulding seal with some double-sided tape remaining may cause poor adhesion. Perform this procedure until the tape is sufficiently removed.
        • Make sure to use a cloth when removing. Using a screwdriver, etc., may cause damage and poor adhesion.
      2. Apply primer to the roof rack.

        1. Apply primer to the roof rack on the installation area of the front roof drip side finish moulding seal using a brush or felt.

        NOTE:
        • Replace the brush or felt if it is dirty or has become hardened.
        • Do not touch surfaces to which primer has been applied until the roof rack has been attached.

        2. Let the primer dry sufficiently.

        Recommended drying time

        10 minutes or more (at 23°C (73°F))

        NOTE:

        Do not touch applied surfaces until the primer is dry.

      3. Install a new front roof drip side finish moulding seal.

        1. Using a heat light, heat the roof rack.

        Standard

        Item Temperature Item Temperature
        Roof Rack 20 to 30°C (68 to 86°F) - -
        WARNING:
        • Do not touch the heat light and heated parts.
        • Touching the heat light may result in burns.
        • Touching heated parts for a long time may result in burns.
        NOTE:

        Do not heat the roof rack excessively.

        2. Remove the release paper from the front roof drip side finish moulding seal.

        HINT:

        After removing the release paper, keep the exposed adhesive free from foreign matter.

        3. Install the front roof drip side finish moulding seal as shown in the illustration.

        HINT:

        • Install the front roof drip side finish moulding seal along the location line on the roof rack.
        • Press the front roof drip side finish moulding seal firmly to install it.
  4. INSTALL REAR ROOF RACK LEG

    Torque: 5.5 N.m (56 kgf/cm, 49 in.lbf)

  5. INSTALL FRONT ROOF RACK LEG

    Torque: 5.5 N.m (56 kgf/cm, 49 in.lbf)

  6. INSTALL NO. 2 ROOF SIDE GARNISH LID
  7. INSTALL NO. 1 ROOF SIDE GARNISH LID
